High Speed Bubble Film Machine

YHPEG-4LC high-speed bubble film machine uses LDPE and LLDPE as raw materials, is fully automatic PLC controlled, and can reach a speed of 30m/min. It can produce 2-4 layers of bubble film and is suitable for processing a variety of materials. It is efficient and intelligent, and is an ideal choice for bubble film production.

Get a quote

Download

Description

The YHPEG-4LC high-speed bubble film machine.demonstrates outstanding performance in the bubble film production domain. These machines primarily utilize LDPE and LLDPE particles as raw materials. Their equipment encompasses crucial components like the extrusion system, molding system, traction system, and winding system. The extrusion system features an advanced screw design, guaranteeing the uniform melting of raw materials. The molding system precisely governs the shape and size of film bubbles, while the traction system operates stably and efficiently, and the winding system accomplishes neat winding.
Both machines are designed to automate the production of bubble film using high-pressure polyethylene as the base material, with the addition of auxiliary materials leading to the formation of uniform bubbles through high-temperature extrusion and vacuum forming. The production process is meticulously controlled by a computer, ensuring consistent quality and high output efficiency. They offer excellent raw material compatibility, suitable for processing various materials. A wide range of bubble sizes can be achieved through a selection of molds to meet diverse requirements. By employing scientific water cooling and air cooling methods, the production efficiency of bubble film is improved, and the three-dimensionality of bubbles is enhanced. The use of frequency conversion speed regulation in the machines not only augments the flexibility of production speed control but also reduces energy consumption. Moreover, the YHPEG-4LC machine has a very high degree of automation, adopting fully automatic PLC control for easy operation. Its intelligent control system monitors the equipment's operation status in real time, automatically adjusts parameters, and has a fault self-diagnosis function, minimizing downtime and further enhancing production efficiency. Overall, these machines provide effective protection and insulation for packaged products, making them highly sought-after in numerous industries.

Main Technical Variables

Model	Max. Width	Screw Diameter	Screw L:D	Extruder MotorPower	Take-up Motor Power	VacumPump	Speed	Power
YHPEG-1300	1300mm	Φ70/55mmΦ50mm	33:1	22/11kw 11kw	2.2kw	1.1kw	10-30m/min	100kw
YHPEG-1600	1600mm	Φ75/60mmΦ50mm	33:1	30/15kw 15kw	2.2kw	1.5kw	10-30m/min	130kw
YHPEG-1800	1800mm	Φ75/60mmΦ50mm	33:1	30/15kw 15kw	2.2kw	1.5kw	10-30m/min	150kw
YHPEG-2000	2000mm	Φ80/65mmΦ50mm	33:1	37/18.5kw 18.5kw	2.2kw	2kw	10-30m/min	160kw
YHPEG-2500	2500mm	Φ85/70mmΦ50mm	33:1	37/22kw 22kw	3kw	2.2kw	10-30m/min	178kw

* We will no longer informyouifthere is any data change.

Optional equipment

1. Chiller
2. Automatic Vacuum Feeder
3. Auto Changing Sieve
4. Blender
5. Scrap Reverse
6. Grinder
7. Auto Rewinder
8. In line perforated unit
9. Huangyan T-die
