Plastic Bubble Film Making Machine

Plastic Bubble Film Making Machine is a perfect combination of efficiency and quality. The conventional model can produce 50 kg/hour and the fastest can reach 100 kg/hour, meeting the production needs of different scales. The foam roller can be customized in different shapes to provide personalized production solutions.
Description

The plastic bubble film machine adopts a one-time molding process to improve production efficiency. The unit has a scientific and reasonable structural design and runs smoothly and reliably. It can perform well whether it is long-term continuous operation or coping with different production tasks. It is easy to operate and maintain, reducing worries.



The bubble film produced has good transparency, and the good cushioning effect can effectively protect the items from impact during transportation and storage.



In the use of raw materials, you can choose new materials or make full use of recycled materials to reduce production costs. If you want to produce colored bubble film, you can also add masterbatch to meet the personalized needs of packaging color.



Main Technical Variables

Model

RK-1000

RK-1200

RK-1500

RK-2000

Screw diameter

Φ60mm

Φ65mm

Φ75mm

Φ90mm

Film width

1000mm

1200mm

1500mm

2000mm

Max. Output

50kg/h

65kg/h

80kg/h

100kg/h

Main motor power

15kw

15kw

18.5kw

37kw

Power

28kw

38kw

50kw

80kw

L/D

30:1

30:1

30:1

30:1

Power supply

380/3/4/50(Volt/Ph/Line/Hz)

Weight

4000kg

4200kg

4500kg

7000kg

Overall Dimenson(LxWxH)

9.0x3.5x2.5m

9.5x3.8x2.5m

10.0x4.0x2.6m

11.5x4.8x4.0m



* We will no longer inform youif there is any data change.





Optional equipment

Note: ALL equipments supplied by my company are not include attached unit (water. air, electricity)
