Three and Five Layers Co-Extrusion Film Blowing Machine

SJ-GS Three and Five Layers Co-Extrusion Film Blowing Machine adopts advanced technologies such as forced feeding, precision heating, double cutting and double collecting, and computer control.
Description
Performance and Characteristics



Ruikang's three-layer and five-layer co-extruded blown film machine is widely used in the production of various high transparency packaging films by co-extruding multiple layers of different plastic materials together to produce films with multiple functions.

- Computerised centralised control system with high degree of automation.
- IBC internal cooling system for fast curing of plastic films.
- High speed production of large quantities of film up to 400kg/hour.
- Horizontal rotary traction system for more stable production quality.





Main Technical Variables



Model

SJ55-GS1300

SJ60-GS1500

SJ65-GS1800

SJ70-GS2300

Max.Lay fat width (mm)

1200mm

1400mm

1700mm

2100mm

Film layer

3

3

3

3

Film thickness (mm)

0.02-0.12mm

0.02-0.12mm

0.02-0.12mm

0.02-0.12mm

Max.output (kg/h)

200kg/h

250kg/h

300kg/h

400kg/h

Raw material

LLDPE、LDPE、EVA

Screw diameter (mm)

φ45/φ55/φ45

Φ50/φ60/φ50

Φ60/φ70/φ60

Φ75/φ90/φ75

Screw L/D ratioL/D

30:1

30:1

30:1

30:1

Screw Max.rotation Speed (r/min)

100r/min

100r/min

100r/min

100r/min

Extruder driving power (kw)

18.5/30/18.5kw

22/37/22kw

30/45/30kw

55/90/55kw

Die structure

IBC Film tube inner cooling system

Air-ring structure

Double vents air ring

Reversting haul-off system

Horizontal± 180°

Take-off Wide-up speed (r/min

45-120r/min

Total Power (kw)

150kw

280kw

280kw

350kw

Overall dimensions (mm)

Acording to actual machine

Weight (T)

Acording to actual machine



*We will no longer inform you if there is any data change.
