Single Layer Blown Film Machine

Name: Single Layer Blown Film Machine
Brand: Ruikang
SKU: 00029
Rating: 4.1 (65 reviews)

RK-SJA50/800 Single Layer Blown Film Machine is 38 chrome molybdenum aluminum alloy by high-quality nitriding treatment, the screw is also made of cemented carbide coating, high hardness, wear and corrosion resistance.

Get a quote

Download

Description

Performance and characteristics

Ruikang's Single Layer Blown Film Machine represents a pinnacle of innovation and efficiency in the field of blown film manufacturing. With an impressive production speed of up to 80m/min, it is capable of churning out high-quality supermarket bags and vest bags that not only exhibit a visually appealing finish but also possess remarkable tensile strength, ensuring their durability and reliability in various applications.
This machine is equipped with a host of advanced features that contribute to its outstanding performance. The heating system of each section is designed with automatic temperature control, which not only optimizes the energy consumption, making it an environmentally friendly choice, but also ensures the stability and consistency of the film production process. The spiral, haul-off, and winding mechanisms all incorporate stepless frequency conversion technology, allowing for precise and flexible control, which in turn results in enhanced product quality and uniformity.
The cylindrical head with a spiral core is a key component that sets this machine apart. It enables the raw materials to be plasticized thoroughly, leading to products with excellent plasticity and high strength. This design not only improves the overall quality of the bags but also reduces the likelihood of defects and weaknesses, ensuring that the end products meet the highest standards of the market. Overall, Ruikang's Single Layer Blown Film Machine offers a comprehensive solution for businesses looking to enhance their production capabilities and produce top-notch blown film products with ease and efficiency.

Ruikang's Single Layer Blown Film Machine is highly productive, with a speed of up to 80m/min. The supermarket bags and vest bags made by the machine are aesthetically pleasing and have strong tensile strength.

- The heating of each section adopts automatic temperature control, energy saving and environmental protection.
- Spiral, haul-off and winding all adopt stepless frequency conversion.
- The cylindrical head with spiral core makes the products plasticise well and have high strength.

Main Technical Variables

Model	RK-SJA40/28-700	RK-SJA45/28-800	RK-SJA45/30-800
Screw diameter	45mm	50mm	55mm
Screw length to diameter ratio	30:1	30:1	30:1
Main motor power	7.5kw	11kw	15kw
heating power	11.75kw	13.2kw	15kw
Number of temperature control segments	4	5	5
The maximum amount of extrusion	HDPE26kg/h LDPE35kg/h	HDPE34kg/h LDPE45kg/h	HDPE38kg/h LDPE48kg/h
Product thickness	0.006-0.04mm	0.006-0.04mm	0.006-0.08mm
Traction and winding speed	8-80m/min	8-80m/min	8-80m/min
Traction and winding width	700mm	800mm	800mm
Winding form	Surface coiling	Surface coiling	Surface coiling
Body height	3850mm	4150mm	4150mm
Covers an area	5000*2500mm	5000*2600mm	5000*2600mm
Total water flow of the unit	4L/min	4L/min	4L/min
Total unit weight (approx.)	2000kg	2100kg	2300kg
Total power of unit	23kw	28kw	34kw
Diameter of common die	40/50/60/120
Applicable raw materials	HDPE LDPE LL .DPE

*We will no longer inform you if there is any data change.
