Ruikang's RK-ABA 3 Layer Film Blowing Machine is a top-notch equipment in packaging material production. With a speed up to 100m/min, it co-extrudes three plastic melts precisely for versatile three-layer films.
It features 30% power reduction via energy-saving devices and an accurate automatic control system. The water cooling device boosts film durability. Handling materials like HDPE, LDPE, LLDPE, it has adjustable film width (e.g., 600 - 1000mm for RK-ABA1100) and thickness (0.015 - 0.08mm).
The extruder has quality components; screw diameter varies, and the die rotates 360° for uniform film. Optional equipment like Auto Loader and Corona is available. Overall, it's a reliable solution for high-quality plastic films in packaging.
- Equipped with energy-saving devices, the machine saves 30% of power consumption.
- High production efficiency, up to 100m/min.
- Automatic control system for precise adjustment of the production parameters.
- Water cooling device for curing the plastic film.
Model |
RK-ABA1100 |
RK-ABA1300 |
RK-ABA1500 |
Suitable Material |
HDPE/L DPE/LLDPE |
HDPE/LDPE/LLDPE |
HDPE/LDPE/LLDPE |
Film Width |
600-1000mm |
800-1200mm |
900-1400mm |
Film Thickness |
0.015-0.08mm |
0.015-0.08mm |
0.015-0.08mm |
Max Extrusion Output |
110kg/hr |
130kg/hr |
150kg/hr |
Extruder |
|
||
Screw Diameter |
Φ55x2 |
Φ60x2 |
Φ65x2 |
Screw UD Length |
30:1 |
30:1 |
30:1 |
Screw Material |
Sacm-645/38 Crmoala(Bimetallic) |
Sacm-645/38 Crmoala(Bimetallic) |
Sacm-645/38 Crmoala(Bimetallic) |
Cylinder Material |
Sacm-645/38 Crmoala(Bimetallic) |
Sacm-645/38 Crmoala(Bimetallic) |
Sacm-645/38 Crmoala(Bimetallic) |
Cylinder Cooling |
180wx1-2 |
180wx2-2 |
180wx2-2 |
Driving Motor |
15KWx2 |
18.5KWx2 |
22KWx2 |
Temperature Control |
3 |
3 |
4 |
Average Power-consume |
38kw |
45kw |
52kw |
Type of Die |
|
||
Die Size |
Φ60mm |
Φ80mm |
Φ100mm |
Rotary |
360° |
360° |
360° |
Temperature Control |
2 |
2 |
2 |
Air Blower |
5.5kw |
7.5kw |
11kw |
Take -upunit |
|
||
Roller Width |
φ140x1100 |
Φ160x1300 |
Φ160x1500 |
Take-up Speed |
10-100m/min |
10-100m/min |
10-100m/min |
Take-up Motor |
1.1kw |
1.1kw |
1.5kw |
Winding Unit |
Automatic Winding Or Normal Winding |
||
Winding Motor |
10N.m |
16N.m |
16N.m |
Winding Speed |
10-100m/min |
10-100m/min |
10-100m/min |
Outine Diameter (LxWxH) |
6.5x2.1x4.8m |
7x2.3x6.5m |
7.5x2.5x7.8m |
*We will no longer inform you if there is any data change.
1. Auto Loader
2. Corona
3. Die Rotary Device
4. Air Compressor
5. Mechanics Screen Changer
6. Weight Measurement Control System
