GH-DL600-DL1000 High speed double layer cold-cutting bag making machine

High speed Double Layer Plastic Bag Production Machine

Name: High speed Double Layer Plastic Bag Production Machine
Brand: Ruikang
SKU: 00030
Rating: 4.1 (65 reviews)

Ruikang High speed Double Layer Plastic Bag Production Machine with precise management of production parameters, including bag size, cutting length, etc., is widely used in box and gift industries.

Get a quote

Download

Description

Features

Ruikang high-speed double-layer plastic bag production machine is a remarkable piece of equipment in the packaging industry. It showcases outstanding performance with a production speed that can reach up to 200 pcs/min, making it highly efficient for manufacturing various types of bags such as shopping bags and flat bags, and even suitable for large rubbish bags.
Equipped with a state-of-the-art touch screen and a reliable PLC control system, it offers a high level of automation, simplifying the operation process for users. The advanced hot cutting technology it employs enables precise cutting of the plastic film and effective heat sealing, ensuring the quality and integrity of the produced bags. The automatic feeding system plays a crucial role by evenly feeding the plastic film into the production line, maintaining a smooth and uninterrupted production flow.
Similar to our renowned Plastic Pouch Making Machine, this high-speed double-layer plastic bag production machine is built with durability and robustness in mind. It features an excellent alarm system to quickly address any potential issues, along with an intelligent temperature controller for precise temperature regulation, guaranteeing clean and accurate sealing. Additionally, it has the capability to produce bags with punched holes and linked bags consisting of 5 - 12 individual bags, further enhancing its versatility and practicality. Overall, it delivers exceptional performance over an extended period, meeting the demands of modern packaging production with ease.

Ruikang high-speed double-layer plastic bag production machine, the machine production speed, the fastest up to 200 pcs/min, suitable for shopping bags, flat bags, can be used as large rubbish bags.

- Equipped with touch screen and PLC control system, high automation
- Adopting hot cutting technology to cut plastic film and heat sealing.
- Automatic feeding system can feed the plastic film into the production line evenly.

Main Technical Variables

Model	GH-DL600	GH-DL700	GH-DL800	GH-DL900	GH-DL1000
Width of sealing &cutting	500mm	600mm	700mm	800mm	900mm
Length of sealing& cutting	700mm	1200mm	1200mm	1500mm	1600mm
Speed of bag-making	240- 300pc/min	240- 300pc/min	150- 260pc/min	150- 200pc/min	150- 200pc/min
Power of motor	1.1kw	1.5kw	1.5kw	2kw	2kw
Weight	700kg	850kg	850kg	1000kg	1000kg
Outline dimension	3200x1200x1700mm	3500x1300x1700mm	3500x1300x1800mm	3700x1600x2000mm	3800x1800x2100mm

*We will no longer inform you if there is any data change.

Optional equipment

1. Yaskawa Servo Motor
2. Sick Photocell
3. Automaticpuncher
